Belden 9311 20 AWG 50 Ohm RG-58 Coax Cable TC Shielded PE/PVC 300V Black

This RG-58 wireless transmission coaxial cable is a 50-ohm, 300V-rated cable designed for point-to-point and point-to-multipoint wireless antenna communication and wireless microphone applications. It features a 20 AWG stranded tinned copper conductor, polyethylene (PE) foam insulation, Duofoil® tri-laminate (alum+poly+alum) tape shield (100% coverage), tinned copper braid shield (55% coverage), and a black polyvinyl chloride (PVC) jacket for reliable signal protection in indoor environments.

Applications

9311 is designed for point-to-point and point-to-multipoint wireless antenna communication, wireless microphones, two-way radios, amateur (Ham) radio, low power FM, GPS, RFID (Radio Frequency Identification).

Construction

• 20 AWG stranded (19x32) tinned copper conductor
• Polyethylene (PE) insulation, white
• Duofoil® tri-laminate (alum+poly+alum) (100% coverage)
• Tinned copper braid shield (55% coverage)
• Black Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
• Flammability / Reaction to Fire: UL 1685 UL Loading
• CPR Compliance: CPR Euro class: Eca
• NEC / UL Compliance: Article 800, CM
• CEC / C(UL) Compliance: CM
• European Directive Compliance: EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• AWM Compliance: AWM 1354 (30 V 80°C)
• APAC Compliance: China RoHS II (GB/T 26572-2011)
