Belden 9223 22 AWG Audio Coax Low Noise Cable 50 Ohm RG-58/U TC Shielded PE/PVC 1900V Black

This RG-58/U audio low noise coaxial cable is a 50-ohm, 1900V-rated cable designed for low noise microphone and analog audio applications. It features a 22 AWG stranded tinned copper conductor, black inner polyethylene (PE) conductive insulation layer, white polyethylene (PE) insulation, Duobond® II tape shield, tinned copper braid shield, and a black polyvinyl chloride (PVC) jacket for reliable signal protection in indoor environments.

Applications

9223 is designed for low noise microphone, analog audio, and instrumentation.

Construction

• 22 AWG stranded (7x30) tinned copper conductor
• Polyethylene (PE) conductive insulation, black
• Polyethylene (PE) insulation, white
• Duobond® II tri-laminate (alum+poly+alum) (100% coverage)
• Tinned copper braid shield (95% shield)
• Black Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor (Not Riser or Plenum), Indoor
• Sustainability: CA Prop 65
• CPR Compliance: CPR Euro class: Eca; CPR UKCA Class: Eca
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), REACH, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 9223 Technical Data Sheet.
