Belden 85102 16/2C High Temperature Electronic Cable TC NS ETFE/ETFE 300V Clear

This 16 AWG 2 conductor non-shielded high temperature electronic cable is designed for audio, control, and instrumentation applications. It features stranded tinned copper conductors with ETFE insulation and a clear ETFE jacket.

Applications

85102 is designed for extreme high/low temperature environments; chemical resistant; low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, …); instrumentation.

Construction

• 16 AWG stranded (19x29) tinned copper conductors
• 2 conductors: black, white
• Ethylene Tetrafluoroethylene (ETFE) insulation
• Clear Ethylene Tetrafluoroethylene (ETFE) outer jacket

Standards and Compliance

• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 85102 Technical Data Sheet .
