Southwire TelcoFlex 1/0-1C L4 KS24194 600V

Southwire

SKU:
114208-BLK
$0.00/ft
Southwire TelcoFlex 1/0-1C L4 KS24194 600V
Minimum Purchase:
1 ft
$0.00/ft

Description

TelcoFlex 4

600 Volts, Copper Conductor
Single Conductor Central Office Power Wire and Cable
Class l Flexible Strand With Braid
CSA approved, Non-Halogen Insulation

CONSTRUCTION
Conductors
  • Class I modified bunched (8 AND 6 AWG) or rope-bunched (4 AWG and larger) stranded tin-coated copper conforming to ASTM B-33
Insulation
  • 90°C / 105°C rated limited smoke, non-halogen TelcoHyde® 5221.
Separator
  • On sizes 6 AWG and larger, a 1 mil clear Mylar tape shall be applied over the insulation.
Covering
  • On all sizes, a natural cotton braid conforming to UL Standard 44 requirements is applied overall.

Standards:

  • UL Listed RHH/ST1
  • FT4- Flame Test
  • VW-1
  • ASTM B-33
  • Physical and Electrical tests in accordance with UL standard 44 requirements
  • CSA AWM I B 105°C

Southwire TelcoFlex IV Central Office Power Cable, 1/0 AWG, Class 1 Flexible Strand With Braid, LSZH, 600 Volts

Color Options:
Black: 57138101
Gray: 57050601
Red: 56967401
Green: 56967201

Click here for Southwire TelcoFlex IV Technical Data Sheet.

Specifications

Brand:
Southwire
AWG:
1/0
Color:
Various
Number of Conductors:
1
Conductor type:
266/.0201
CSA:
FT-4
Insulation:
PER KS-24194 L4
Outside Diameter:
0.560
Putup:
REEL
Temperature:
105 DEGREES CENTIGRADE (221 F)
UL:
UL44 VW-1
Voltage rating:
600V
Weight per Foot:
0.449

Manufacturer Equivalents

Omni Cable item:
TF41/0-01
Southwire item:
57138101, 57050601, 56967401, 56967201
Anixter item:
3BALI-1011-02, 3BALI-1011-09, 3BALI-1011-03, 3BALI-1011-04
