Belden 9681 24/4P RS-232/422 Low Cap Cable TC Shielded CM PE/PVC 300V Chrome

This 24 AWG multi-pair cable supports EIA RS-232/422 data transmission and digital audio applications. It features four twisted pairs of stranded tinned copper conductors insulated with polyethylene (PE) for stable electrical performance. The cable is shielded with an overall Beldfoil® shield (100% coverage) and includes a 24 AWG drain wire to provide effective grounding and reduce susceptibility to external electromagnetic interference. The overall construction is enclosed in a PVC jacket for indoor use.

Applications

9681 is designed for RS-232 extended distance applications; RS-423 applications; computer communications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring.

Construction

• 24 AWG stranded (7x32) tinned copper conductors
• 4 twisted pairs: white/blue & blue/white, white/orange & orange/white, white/green & green/white, white/brown & brown/white
• Polyethylene (PE) insulation
• Overall Beldfoil® shield (100% coverage)
• 24 AWG stranded (7x32) tinned copper drain wire
• Chrome Polyvinyl Chloride (PVC) outer jacket

Standards and Compliance

• Environmental Suitability: Indoor
• Flammability / Fire Resistance: UL 1685 UL Loading, IEC 60332-1-2
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CM
• AWM Compliance: AWM 2919
• CEC / C(UL) Compliance: CM
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 9681 Technical Data Sheet .
