Belden 9487 16/1P 600V Tray Cable TC NS NPLF PVCNYL/PVC Black

This 16 AWG 1 pair high performance instrumentation cable is designed for industrial control and signal transmission in raceways, cable trays, and ducts. It features stranded tinned copper conductors with PVC/Nylon insulation and a black PVC jacket.

Applications

9487 is designed for use in industrial control, raceways, cable trays and ducts, digital control, instruments (4-20ma, 0-10v, ...) low voltage digital control (24v, …), encoders, control circuits, distributed control systems (DCS), programmable logic controllers (PLC), solenoids, valves, actuators and positioners.

Construction

• 16 AWG stranded (19x29) tinned copper conductors
• 1 pair: black and red
• Polyvinyl Chloride and Nylon (PVC-NYL) insulation
• Black Polyvinyl Chloride (PVC) jacket with ripcord

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance
• Flammability / Fire Resistance: UL1685 UL Loading, IEEE 1202, FT4
• CPR Compliance: CPR Euro class: Eca
• NEC / UL Compliance: Article 336, Article 760, NPLF, TC
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 9487 Technical Data Sheet.
