Belden 9402 20/2P Audio Control and Instrumentation Cable TC Inner Shield CMG SR-PVC/PVC 300V Chrome

This 20 AWG two pair inner shielded cable is engineered for reliable signal transmission in audio, control, and instrumentation systems. It features stranded tinned copper conductors insulated with semi-rigid polyvinyl chloride (SR-PVC) and individually Beldfoil® shielded (100% coverage) pairs to ensure signal integrity in noisy environments. The assembly includes a 22 AWG drain wire for simplified grounding, a polyester tape separator, and is finished with a chrome PVC jacket suitable for indoor industrial and commercial use.

Applications

9402 is designed for low-voltage analog signaling (4-20ma, 0-10V, ...), low voltage digital control (24v, ...); line level audio; computer communication; panel wiring.

Construction

• 20 AWG stranded (7x28) tinned copper conductors
• 2 twisted pairs: red and black, green and white
• Semi-Rigid Polyvinyl Chloride (SR-PVC)
• Individually Beldfoil® aluminum-polyester foil (100% coverage) with each pair
• 22 AWG stranded (19x34) tinned copper drain wire
• Polyester tape separator
• Chrome Polyvinyl Chloride (PVC) outer jacket

Standards and Compliance

• Environmental Suitability: Indoor
• Sustainability: CA Prop 65
• Flammability / Fire Resistance: UL 1685 FT4 Loading, FT4
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CMG
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark
• UK Regulation Compliance: UKCA Mark

Click here for the Belden 9402 Technical Data Sheet .
