Belden 9312 12/1P 300V Power-Limited Tray Cable TC Shielded PLTC/ITC/CL3R PVC/PVC Chrome

This 12 AWG 1 twisted pair power limited tray cable (PLTC) is a shielded high performance instrumentation and control cable. It features stranded tinned copper conductors, polyvinyl chloride (PVC) insulation, overall Beldfoil® shield, drain wire, cotton serve separator, and a PVC outer jacket with ripcord. This cable is UL rated CL3R, ITC, and PLTC and suitable for indoor and outdoor applications.

Beldfoil® is Belden’s patented aluminum/polyester shield that delivers 100% coverage to block EMI and RFI, providing lightweight, flexible protection for clear signal transmission in audio, control, and data cables.

Applications

9312 is designed for use in instrumentation, sensors, valves, positioners, 4-20mA and 0-10V.

Construction

• 12 AWG stranded (65x30) tinned copper conductors
• 1 twisted pair: black and red
• Polyvinyl Chloride (PVC) insulation
• Overall Beldfoil® bi-laminate (alum + poly) shield (100% coverage)
• 14 AWG (19x26) tinned copper drain wire
• Cotton Serve Separator
• Chrome Polyvinyl Chloride (PVC) jacket with ripcord

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance
• Flammability / Fire Resistance: UL1685 (FT4 Loading), FT4, IEEE 1202, T-29-520
• NEC / UL Compliance: Article 725, Article 727, CL3R, ITC, PLTC
• AWM Compliance: AWM 2464
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)
