Belden 88104 24/4P RS-232/422 Low Cap Cable TC Shielded CMP FFEP/PVDF 300V Gray

This 24 AWG multi-pair cable supports EIA RS-232/422 data transmission and digital audio applications. It features four twisted pairs of stranded tinned copper conductors insulated with foam fluorinated ethylene propylene (FFEP) to provide low capacitance and stable electrical performance. The cable is shielded with an overall Beldfoil® shield (100% coverage) and includes a 24 AWG drain wire to provide effective grounding and reduce susceptibility to external electromagnetic interference. The overall construction is enclosed in a polyvinylidene fluoride (PVDF) jacket and is rated for plenum (CMP) installations.

Applications

88104 is designed for extreme high temperature environments; rs-232 extended distance applications; rs-422 applications; computer communication; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring.

Construction

• 24 AWG stranded (7x32) tinned copper conductors
• 4 twisted pairs: white/blue stripe & blue/white stripe, white/orange stripe & orange/white stripe, white/green stripe & green/white stripe, white/brown stripe & brown/white stripe
• Foam Fluorinated Ethylene Propylene (FFEP) insulation
• Overall Beldfoil® shield (100% coverage)
• 24 AWG stranded (7x32) tinned copper drain wire
• Gray Polyvinylidene Fluoride (PVDF) outer jacket

Standards and Compliance

• Flammability / Fire Resistance: NFPA 262 Plenum Flame Test (UL 910)
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CMP
• CEC / C(UL) Compliance: CMP
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 88104 Technical Data Sheet .
