Belden 83930 20/1P JX Thermocouple Extension Cable NS CL3P/PLTC FEP/FEP 300V Black

This 20 AWG multi-conductor cable is a 300V PLTC/CL3P-rated solution designed for precise temperature measurement in industrial environments. As a Type JX thermocouple extension cable, it utilizes stranded iron and constantan extension-grade conductors to extend signals from Type J thermocouples while maintaining thermal accuracy.

The conductors are insulated with Fluorinated Ethylene Propylene (FEP), providing excellent high-temperature performance, chemical resistance, and electrical stability. The cable features a black FEP outer jacket that is sunlight-resistant and suitable for installation in plenums, raceways, and cable trays where a plenum-rated thermocouple extension cable is required.

Applications

83930 is designed for industrial control, raceways cable trays and ducts, digital control, instruments (4-20ma, 0-10v, ...), low voltage digital control (24v, …), RTD, control circuits, distributed control system (DCS), programmable logic controller (PLC), solenoids, valves, actuators, positioners.

Construction

• 20 AWG stranded (7x28) iron (positive) and constantan (negative) conductors
• 1 pair: white and red
• Fluorinated Ethylene Propylene (FEP) insulation
• Black Fluorinated Ethylene Propylene (FEP) outer jacket

Standards and Compliance

• Environmental Suitability: Indoor, Outdoor, Sunlight Resistant
• Flammability / Fire Resistance: NFPA 262, UL 910 (Plenum)
• NEC / UL Compliance: Article 725
• European Directive Compliance: EU CE Mark, RoHS 2 (2011/65/EU), RoHS 2 Amendment (2015/863/EU), WEEE (2012/19/EU)
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Other Standard Compliance(s): ISA MC 96.1-1982 Type JX
