Belden 82777 Multi-Conductor - CMP Rated (Plenum) Cable 3-Pair 22 AWG FS FEP FLMRST Natural

Belden

SKU:
82777

Call 888-681-1768 for Price and Lead Time

Belden 82777 Multi-Conductor - CMP Rated (Plenum) Cable 3-Pair 22 AWG FS FEP FLMRST Natural
Minimum Purchase:
1 ft
22 AWG stranded (7x30) tinned copper conductor, FEP insulation, twisted pairs individually shielded with Beldfoil® (100% coverage), overall jacket per table below, 22 AWG stranded tinned copper drain wire. View full description

Call 888-681-1768 for Price and Lead Time

Description

Belden 82777 Multi-Conductor - CMP Rated (Plenum) Cable 3-Pair 22 AWG FS FEP FLMRST Natural

Audio, Control & Instrument Cable, 22 AWG stranded (7x30) tinned copper conductor, FEP insulation, twisted pairs individually shielded with Beldfoil® (100% coverage), overall jacket per table below, 22 AWG stranded tinned copper drain wire.

Click here for Belden 82777 Technical Data Sheet.

Specifications

Brand:
Belden
AWG:
22
Capacitance:
35
Color:
Natural
Number of Conductors:
3 Pairs
Conductor type:
STRANDED CONDUCTOR, TINNED COPPER
Construction:
INDIVL/FOIL SIDE & DRAIN OUT
Insulation Thickness (inches):
0.011
Insulation:
FEP, FEP - FLUORINATED ETHYLENE PROPYLENE
Jacket Thickness (inches):
0.017
Jacket type:
Flamarrest--natural, FRPVC-FLAME RETARDANT PVC
Manufacturer:
Belden
Manufacturers item number:
82777 8771000
NEC:
UL LISTED ART 800 PLENUM
Ohms:
46
Outside Diameter:
0.237
Pairs:
3
Plenum/Riser:
PLENUM
RoHS Compliant:
YES
Shielded/Unshielded:
YES
Shield 1 type:
FOIL SHIELDED - ALUM/MYLAR
Number of Strands:
7x30
Temperature:
60 DEGREES CENTIGRADE
UL:
UL LSTED WIRE MISC.
Voltage rating:
300 VOLTS AC
Weight per Foot:
0.03510

Manufacturer Equivalents

Alpha Wire item:
58613
Anixter item:
B82777
Belden item:
82777 8771000
General Cable item:
C8131
Honeywell item:
3264
Wirexpress item:
B82777
