Description
This 24 AWG multi-conductor cable supports EIA RS-232 data transmission, computer communications, and low-voltage analog and digital control plenum applications. It features 9 pairs of stranded tinned copper conductors insulated with Fluorinated Ethylene Propylene (FEP) for stable electrical performance. The cable is shielded with an overall Beldfoil® shield (100% coverage) and includes a 24 AWG drain wire to provide effective grounding and reduce crosstalk. The overall construction is enclosed in a PVC jacket for indoor CMP-rated installations.
Applications
82509 is designed for indoor plenum applications; RS-232 applications; computer communications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring.
Construction
- 24 AWG stranded (7x32) tinned copper conductors
- 9 pairs: black & red, black & white, black & green, black & blue, black & yellow, black & brown, black & orange, red & white, red & green
- Fluorinated Ethylene Propylene (FEP) insulation
- Overall Beldfoil® shield (100% coverage)
- 24 AWG stranded (7x32) tinned copper
- Natural Polyvinyl Chloride (PVC) outer jacket
Standards and Compliance
- Environmental Suitability: Indoor - Plenum, Indoor
- Flammability / Fire Resistance: NFPA 262 Plenum Flame Test (UL910)
- NEC / UL Compliance: Article 800, CMP
- CEC / C(UL) Compliance: CMP
- European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- APAC Compliance: China RoHS II (GB/T 26572-2011)
Click here for the Belden 82509 Technical Data Sheet .
