Belden 82418 18/4C Audio Control and Instrumentation Cable TC Shielded CMP FEP/PVC 300V Natural

This 18 AWG 4 conductor electronic cable is designed for low-voltage signal, control, audio, voice, and panel wiring applications in indoor plenum spaces. It features stranded tinned copper conductors with FEP insulation, an overall Beldfoil® shield with a 20 AWG tinned copper drain wire, and a PVC jacket for reliable signal protection. The cable is UL-rated CMP for 300V service.

Applications

82418 is designed for indoor plenum applications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage control (24v, …); line level audio; voice communications; panel wiring.

Construction

• 18 AWG stranded (19x30) tinned copper conductors
• 4 conductors, black, white, red, green
• Fluorinated Ethylene Propylene (FEP) insulation
• Overall Beldfoil® Shield (100% coverage)
• 20 AWG (19x32) tinned Copper drain wire
• Natural Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor - Plenum, Indoor
• Sustainability: CA Prop 65
• Flammability / Reaction to Fire: NFPA 262, UL 910 (Plenum)
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, CMP
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Non-Plenum Number: 9418

Click here for the Belden 82418 Technical Data Sheet .
