Belden 8218 27 AWG 75 Ohm RG-59 Mini Coax Cable BCCS Shielded PE/PVC 30V Black

This RG-59 miniature coaxial cable is a 75-ohm, 30V-rated cable designed for standard analog video applications. It features a 27 AWG stranded Bare Copper Covered Steel (BCCS) conductor, polyethylene (PE) insulation, a 95% tinned copper braid shield, and a Polyvinyl Chloride (PVC) jacket for reliable signal protection in indoor environments.

Applications

8218 is designed for video distribution, CCTV installations, and high frequency data transmission.

Construction

• 27 AWG stranded (7x35) Bare Copper Covered Steel conductor (BCCS)
• Polyethylene (PE) insulation
• Tinned copper braid shield (95% coverage)
• Black Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor (Not Riser of Plenum)
• UL AWM Style Compliance: AWM 1354 (30V 60C)
• European Directive Compliance: EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 8218 Technical Data Sheet.
