Description
This 24 AWG multi-pair cable supports EIA RS-232/422 data transmission and computer communication applications. It features eighteen twisted pairs of stranded tinned copper conductors insulated with Datalene® (foam polyethylene) for stable electrical performance. The cable is shielded with an overall Beldfoil® shield (100% coverage) and a 65% coverage tinned copper braid, along with a 24 AWG drain wire to provide effective grounding and reduce susceptibility to external electromagnetic interference. The overall construction is enclosed in a PVC jacket for indoor CM-rated installations.
Applications
8118 is designed for RS-232 extended distance applications; RS-422 applications; computer communications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring.
Construction
- 24 AWG stranded (7x32) tinned copper conductors
- 18 twisted pairs: Western Electric Standard color code
- Foam polyethylene (PE) Datalene® insulation
- Overall Beldfoil® shield (100% coverage)
- Tinned copper braid shield (65% coverage)
- 24 AWG stranded (7x32) tinned copper drain wire
- Chrome Polyvinyl Chloride (PVC) outer jacket
Standards and Compliance
- Environmental Suitability: Indoor (not riser or plenum)
- Flammability / Fire Resistance: UL 1685 FT4 Loading, IEC 60332-1-2
- CPR Compliance: CPR Euroclass: Eca
- NEC / UL Compliance: Article 800, CM
- AWM Compliance: AWM 2919
- CEC / C(UL) Compliance: CM
- European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
- UK Regulation Compliance: UKCA Mark
- APAC Compliance: China RoHS II (GB/T 26572-2011)
Click here for the Belden 8118 Technical Data Sheet .
