Belden 7922A 22/4P Cat5e DataTuff Cable U/UTP CMR/CMX/PLTC PO/PVC Black

This DataTuff® Category 5e cable features 4 bonded pairs of 22 AWG solid bare copper conductors with Polyolefin insulation and a rugged PVC outer jacket. As a DataTuff cable, it is specifically engineered for maximum reliability in harsh industrial environments, offering superior resistance to sunlight and oil. It is rated for PLTC, CMR, and CMX-Outdoor use in tray, conduit, raceway, and outdoor installations.

Applications

7922A is designed for power-limited tray, harsh environment, IIoT, factory or process automation, IP cameras and devices, data communication, etc.

Construction

• 22 AWG solid bare copper conductors
• 4 bonded twisted pairs: white/blue stripe & blue, white/orange stripe & orange, white/green stripe & green, and white/brown stripe & brown
• Polyolefin (PO) insulation
• Black Polyvinyl Chloride (PVC) outer jacket with ripcord

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, Oil Resistance
• Flammability / Fire Resistance: UL 1666 Riser, FT4, IEC 60332-1-2
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 800, Article 725, CMR, CMX-Outdoor, PLTC
• CEC / C(UL) Compliance: CMR
• Data Category: Category 5e
• TIA/EIA Compliance: ANSI/TIA-568.2-D Category 5e
• Third Party Performance Verification: Category 5e
• ISO/IEC Compliance: ISO/IEC 11801-1, IEC 61156-5
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE), REACH: 2020-01-16
• APAC Compliance: China RoHS II (GB/T 26572-2011)
