Belden 3083A 15/1P-18/1P DeviceBus Cable TC I/O Shield CMG/PLTC-ER PVC/FPE/CPE 300V Yellow

This DeviceBus® for ODVA DeviceNet™ Thick cable is a 300V composite cable for industrial automation and power applications. It features a 18 AWG shielded data pair with Foam FPE insulation and a 15 AWG shielded power pair with PVC insulation. Both pairs are individually Beldfoil® shielded, protected by an overall 65% tinned copper braid, and enclosed in a yellow sunlight-resistant CPE jacket for reliable performance in harsh environments.

Applications

3083A is designed for harsh environment, ODVA device-level communication, used with CIP (Common Industrial Protocol) for control, configuration, and data collection between devices, such as sensors and actuators, and higher level devices such as PLC, and PC in industrial automation, bus topology, etc.

Construction

• 1 pair of 15 AWG stranded (19x27) tinned copper conductors (power)
• PVC (Polyvinyl Chloride) insulation, red and black (power)
• 1 pair of 18 AWG stranded (19x30) tinned copper conductors (data)
• FPE (Foam Polyethylene) insulation, blue and white (data)
• Individual Beldfoil® tape on each pair (100% coverage) plus an overall tinned copper braid (65% coverage)
• 18 AWG stranded (19x30) tinned copper drain wire
• Yellow CPE (Chlorinated Polyethylene) outer jacket

Standards and Compliance

• Environmental Suitability: Indoor, Outdoor, Sunlight Resistance, Burial
• Flammability / Fire Resistance: UL 1685 (FT4 Loading), IEEE 1202 FT4
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 725, Article 800, CMG, PLTC
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Other Standard Compliance (s): ODVA Class 2 Thick

Click here for the Belden 3083A Technical Data Sheet .
