Belden 3073F 18/1P DataTray 100Ω Twinax Cable TC Shielded PLTC/ITC/CMG/TC PP/PVC 600V Blue

This 18 AWG 1 pair DataTray® twinaxial cable is a 100-ohm instrumentation and control cable designed for harsh industrial and automation environments. It features tinned copper conductors, flame-retardant polypropylene insulation, an overall Beldfoil® shield with a 55% tinned copper braid, and a PVC jacket. The cable is UL-rated TC for 600V service and PLTC/CMG for 300V service.

Applications

3073F is designed for harsh environments, IIoT, factory or process automation, video, audio, data communication, etc.

Construction

• 18 AWG stranded (7x26) tinned copper conductors
• 1 pair: white and blue
• Polypropylene (PP) insulation
• Outer Beldfoil® shield (100% coverage)
• Tinned copper braid shield (55% coverage)
• Blue Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, UV Resistance, Aerial - when supported by messenger wire
• Sustainability: CA Prop 65
• Flammability / Reaction to Fire: UL 1685 UL Loading, FT1, FT4
• CPR Compliance: CPR Euroclass: Eca
• NEC / UL Compliance: Article 336, Article 725, Article 727, Article 800, CMG, ITC, PLTC, TC
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• UK Regulation Compliance: UKCA Mark
• APAC Compliance: China RoHS II (GB/T 26572-2011)
