Belden 29532C Multi-Conductor - 600V VFD 4/0-3C XLPE/PVC w/Grounds

This 4/0 AWG, 3-conductor VFD motor supply tray cable (TC-ER) from Belden Basics features segmented bare grounding conductors, providing a robust, standard construction solution for variable frequency drive installations where superior grounding and noise control are critical.

Overall dual bare copper tape shields helically applied with 100% coverage for crack resistance and high frequency noise conduction.

The Exposed Run (TC-ER) rating means this cable meets crush and impact requirements, so it can be installed outside of a cable tray without continuous mechanical protection, unlike standard tray cables that must be enclosed in conduit, raceway, or similar protective systems.

Applications

29532C is designed for use as a variable frequency drive (VFD) cable, AC motor and drive system, Class 1 Division 2 Locations

Construction

• 3 conductors, 4/0 AWG (19x10) bare copper
• 3 segmented ground wire, 8 AWG (7x16) bare copper (3 totaling 3 AWG)
• XLPE (cross-linked polyethylene) insulated conductors, black and numbered
• Overall dual bare copper tape shield helically applied, 100% coverage
• Black PVC (polyvinyl chloride) outer jacket with ripcord

Standards and Compliance

• Environmental Suitability: Indoor, Outdoor, Sunlight Resistant, Burial
• Sustainability: CA Prop 65
• Flammability / Fire Resistance: UL 1685 UL Loading, IEEE 1202 FT4
• NEC / UL Compliance: Article 336, Type TC-ER, XHHW-2
• AWM Compliance: AWM I/II A/B
• ICEA Compliance: S-95-658
• European Directive Compliance: EU CE Mark; EU Directive 2015/863/EU (RoHS 2 amendment); EU Directive 2011/65/EU (RoHS II); EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Other Standard Compliance: P-07-KA070003-MSHA
