Belden 28600A 18/6C 600V Tray Cable BC NS NPLF/TC-ER PVC-NYL/PVC Black

This 18 AWG 6 conductor tray cable (TC-ER) is a non-shielded power and control cable. It features stranded bare copper conductors, polyvinyl chloride + nylon (PVC/Nylon) insulation, and a PVC outer jacket with ripcord. This cable is UL rated non-power-limited fire alarm (NPLF) and suitable for indoor, outdoor, and burial applications.

The Exposed Run (ER) rating on this cable means it meets crush and impact testing requirements, and is therefore tough enough to run outside a cable tray without additional protection, unlike standard tray cables which must be installed inside a conduit, raceway or other protection.

Applications

28600A is designed for use in power and control applications up to 600V; Class 1 Division 2 hazardous locations; recommended cable gland Belden BTC075A0551RA.

Construction

• 18 AWG stranded (7x26) bare copper conductors
• 6 conductors: black, red, blue, orange, yellow, brown
• Polyvinyl Chloride + Nylon (PVC/NYL) insulation
• Black Polyvinyl Chloride (PVC) jacket with a ripcord

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, UV Resistance, Burial
• Flammability / Fire Resistance: UL 1685 UL Loading, FT4, IEEE 1202
• CPR Compliance: CPR Euro class: Eca
• NEC / UL Compliance: Article 336, TC-ER, TFFN
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU (RoHS 2 amendment), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
