Belden 1529A Multi-Conductor - 300V PLTC 18/3PR + 22/1C BC PVC/PVC SHLD

This 18 AWG 3 twisted pair power limited tray cable (PLTC), is a 300V UL-rated instrumentation and control cable. It has an additional 22 AWG communication conductor as well as overall shielding with a drain.

Beldfoil is Belden’s patented aluminum/polyester shield that delivers 100% coverage to block EMI and RFI, providing lightweight, flexible protection for clear signal transmission in audio, control, and data cables.

Applications

1529A is designed for use in industrial control, raceways, cable trays and ducts, digital control, instruments (4-20ma, 0-10v, ...),low voltage digital control (24v, …), encoders, control circuits, distributed control systems (DCS), programmable logic controllers (PLC), solenoids, valves, actuators and positioners.

Construction

• 18 AWG stranded (7x26) bare copper conductors
• 3 twisted pairs, black and white
• 22 AWG stranded (7x30) single bare copper communication conductor, orange
• Polyvinyl Chloride (PVC) insulation
• Overall Beldfoil shield (100% coverage)
• 18 AWG (7x26) tinned copper drain wire
• Black Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, Burial
• Flammability / Fire Resistance: UL1685 (FT4 Loading), FT4, IEEE 1202
• NEC / UL Compliance: Article 725, Article 727, Article 800, CMG, PLTC, ITC
• AWM Compliance: 2464
• CEC / C(UL) Compliance: CMG
• European Directive Compliance: EU CE Mark, EU Directive 2015/863/EU, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 1529A Technical Data Sheet.
