Belden 1424A 24/12.5P RS-232/422 Low Cap Cable TC Shielded CM Datalene PE/PVC 300V Chrome

This 24 AWG multi-pair cable supports EIA RS-232/422 data transmission and digital audio applications. It features twelve twisted pairs and one single conductor (12.5P) of stranded tinned copper insulated with Datalene® for stable electrical performance. The cable is shielded with an overall Beldfoil® shield (100% coverage) and includes a 24 AWG drain wire to provide effective grounding and reduce susceptibility to external electromagnetic interference. The overall construction is enclosed in a PVC jacket for indoor use.

Applications

1424A is designed for RS-232 extended distance applications; RS-423 applications; computer communications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, …); line level audio; panel wiring.

Construction

• 24 AWG stranded (7x32) tinned copper conductors
• 12 twisted pairs: Western Electric Standard Color Code
• 1 single conductor: Gray
• Foam polyethylene (PE) Datalene® insulation with pairs and single conductor
• Overall Beldfoil® shield (100% coverage)
• 24 AWG stranded (7x32) tinned copper drain wire
• Chrome Polyvinyl Chloride (PVC) outer jacket

Standards and Compliance

• Environmental Suitability: Indoor (not riser or plenum)
• Flammability / Fire Resistance: UL 1685 FT4 Loading
• NEC / UL Compliance: Article 800, CM
• AWM Compliance: AWM 2919
• CEC / C(UL) Compliance: CM
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (RoHS 2), EU Directive 2012/19/EU (WEEE)
• APAC Compliance: China RoHS II (GB/T 26572-2011)

Click here for the Belden 1424A Technical Data Sheet .
