Belden 1190A 18 AWG RG6 Cable BCCS Quad Shield CM FPE/PE 350V Black

This RG6 broadband coaxial cable is a 75-ohm, 350V UL-rated cable designed for Cable Television (CATV) applications. It features an 18 AWG solid bare copper covered steel conductor (BCCS), gas injected foam polyethylene insulation, Coreguard® flooding compound, quad aluminum shield using dual Duofoil® tape, dual aluminum braids, and a black polyethylene (PE) jacket for reliable signal protection in harsh industrial environments.

Applications

1190A is designed for broadband and Cable Television (CATV).

Construction

• 18 AWG solid Bare Copper Covered Steel (BCCS) conductors
• Polyethylene (PE) Foam insulation (gas injected)
• Coreguard® flooding compound
• Quad shield: Duofoil® (100% coverage), aluminum braid (60% coverage), Duofoil® (100% coverage), aluminum braid (40% coverage)
• Black Polyethylene (PE) jacket

Standards and Compliance

• Environmental Suitability: Outdoor - Water Exposure, Outdoor, Aerial - when supported by messenger wire, Burial
• Flammability / Reaction to Fire: UL 1685 UL Loading
• NEC / UL Compliance: CM, CATV
• CEC / C(UL) Compliance: CM
• European Directive Compliance: EU Directive 2003/11/EC (BFR), EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)

Click here for the Belden 1190A Technical Data Sheet.
