Belden 1120A Multi-Conductor - 600V Tray Cable 18/1PR BC PVCN/PVC SHLD

This 18 AWG 1 twisted pair tray cable (TC), is a 600V UL-rated instrumentation and control cable with a drain and overall Beldfoil shield.

Beldfoil is Belden’s patented aluminum/polyester shield that delivers 100% coverage to block EMI and RFI, providing lightweight, flexible protection for clear signal transmission in audio, control, and data cables.

Applications

1120A is designed for use in industrial control, raceways, cable trays and ducts, digital control, instruments (4-20ma, 0-10v, ...),low voltage digital control (24v, …), encoders, control circuits, distributed control systems (DCS), programmable logic controllers (PLC), solenoids, valves, actuators and positioners.

Construction

• 18 AWG stranded (7x26) bare copper conductors
• 1 twisted pair, black and red
• Polyvinyl Chloride and Nylon (PVC-NYL) insulation
• Overall Beldfoil shield (100% coverage)
• 20 AWG (7x28) tinned copper drain wire
• Black Polyvinyl Chloride (PVC) jacket

Standards and Compliance

• Environmental Suitability: Indoor/Outdoor, Sunlight Resistance, Burial
• Flammability / Fire Resistance: UL1685 (FT4 Loading), FT4, IEEE 1202 FT4
• NEC / UL Compliance: Article 336, Article 760, NPLF, TC
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)

Click here for the Belden 1120A Technical Data Sheet.
